PM/31062 Norgren Air Bags W01-R58-4070 Firestone Industrial Air Spring Bellows 6''X2 Aluminum Part
Specifications and Detail Technical Parameters
Weight: 2.1 kg
G1/2: max. 25 Nm
M8: max. 12 Nm
Nut/ Blind Nut
Top cover screw (nut) teeth: 4 X M8
Bottom cover screw (nut) teeth: 4 X M8
air hole / air inlet / air connector
Air vent / air inlet: G1 / 2
cover
Top cover diameter (width): 153.5 mm
Bottom cover diameter (width): 153.5 mm
Material top and bottom plate: aluminum
Rubber bellows
Maximum diameter 7 bar: 175mm
Rubber bellows stroke: 80mm-195m
bumper block / buffer block
No Bumper Block
Twisted waist/waist ring
Girdle Hoop: a belt hoop
Maximum load is 80 mm height and 8 bar: 1415 daN
Pneumatic application - static characteristic values
Forcr F (kN) |
| Pressure P | bar | 3 | 4 | 5 | 6 | 7 | 8 | Vol V(I) |
| height H(mm) | 160 | 2.28 | 3.52 | 4.5 | 5.5 | 6.54 | 7.6 | 2 |
| 140 | 3.3 | 4.46 | 5.64 | 6.84 | 8.07 | 9.33 | 1.7 |
| 120 | 3.88 | 5.21 | 6.57 | 7.96 | 9.38 | 10.8 | 1.5 |
| 100 | 4.59 | 6.16 | 7.76 | 9.4 | 11.1 | 12.8 | 1.2 |
OE Manufacturer Number
Continental ContiTech: FD 76-14 1/2 M8
Continental ContiTech: FD 76-14 D1 G1/2
Continental ContiTech: FD 76-14 Dl G1/2 M8
Continental ContiTech: FD 76-14 DI G1/2 CR
Continental ContiTech: FD 76-14 DI CR G1/2
Continental ContiTech: FD 76-14 DICR / FD76-14DICR / FD7614DICR
Continental ContiTech Bellow: FD 76-14 / FD76-14 / FD7614
Firestone No.: W01-R58-4070 / W01 R58 4070 / W01R584070
Firestone Style: 6"x2
Dunlop FR: 6"x2 SP1646 (COMPOSITE)
Dunlop FR: 6"x2 SP2917 (ALUMINIUM)
Dunlop UK (Pneuride):A31330 02 01/A313300201
Norgren: PM/31062/PM 31062/PM31062
Nominal 0 (inch) x convolutions: 6"x2 / 6"x2 / 6x2
Parker: 6"x2 9109001A
YS-AIR: YS-160-2VS / YS 160 2VS / YS1602VS
FAQ
1. Who are We?
We are located in Guangzhou, close to Guangzhou Baiyun Airport, with convenient transportation. We have a modern factory and advanced rubber air spring production equipment. Our products are primarily used for shock absorption in commercial vehicles, rail vehicles, and industrial machinery.
2. How do we ensure quality?
We always provide pre-production samples before mass production and conduct a final inspection before shipment.
3. What can you buy from us?
Industrial air springs, bus air springs, truck air springs, truck cab air springs, passenger car air spring shock absorbers, and air pumps.
4. Why should you buy from us instead of other suppliers?
We have specialized in the production and sale of air springs for nearly 20 years. We have also successfully entered the overseas automotive OEM market with competitive prices. We hope to be your sincere business partner and warmly welcome your contact.
5. What services do we provide? Accepted delivery terms: CFR, CIF, EXW, CIP, FOB
Accepted payment currencies: USD, EUR, RMB, GBP
Accepted payment methods: T/T, L/C, PayPal, Western Union
Supported languages: English, Chinese, Russian, Korean
