6" x 3 Triple Air Spring FT 76-20 DI Contitech Industrial Air Spring PM/31063 Norgren
Product Description
Industrial air springs, also commonly known as air isolators or pneumatic actuators, are flexible, sealed containers that use the internal pressure of compressed air as an elastic medium to achieve functions such as support, cushioning, vibration isolation, lifting and height adjustment.
Product Details
| Product Name: | Air Spring |
| Description: | Industrial Air Spring |
| Brand | GUOMAT |
| Model No. | 3B6X3P |
| MOQ: | 1 PCS |
| Warranty: | 12 Months |
| Material: | Rubber |
| Package: | Carton |
| Payment: | L/C T/T West |
| Port of shipment | NINGBO, SHANGHAI, TIANJING, GUANGZHOU, SHENZHEN |
| Shippment: | Bye sea, By air, by DHL Fedex |
Cross Reference Number
Continental ContiTech: FD 76-20 1/2 M8
Continental ContiTech: FD 76-20 Dl G1/2
Continental ContiTech: FD 76-20 Dl G1/2 M8
Continental ContiTech: FD 76-20 DI G1/2 CR
Continental ContiTech: FD 76-20 DI CR G1/2
Continental ContiTech: FD 76-20 DICR/FD76-20DICR/FD7620DICR
Continental ContiTech Bellow: FD 76-20/FD76-20/FD7620
Dunlop FR: 6"x2 SP2923 (ALUMINIUM)
Dunlop : A3 1330 03 01/A313300301
Norgren: PM/31063/PM 31063/PM31063
Nominal 0 (inch)xconvolutions:6"x3/6"x3/6x3
Dimensions
Maximum Diameter 168mm
Space Required 180mm
Minimum Height 109mm
Maximum Height 262mm
Total Stroke 153mm
Static Height 187mm
Effective Area at Static Height 350cm2
Bellows Weight 2.47kg
| Pressure P | bar | 3 | 4 | 5 | 6 | 7 | 8 | Vol.V(I) |
| Height (mm) | 260 | 1.75 | 2.46 | 3.19 | 3.95 | 4.74 | 5.56 | 3.2 |
| 220 | 2.69 | 3.65 | 4.63 | 5.64 | 6.67 | 7.74 | 2.9 |
| 180 | 3.51 | 4.71 | 5.93 | 7.17 | 8.43 | 9.71 | 2.4 |
| 140 | 4.27 | 5.69 | 7.12 | 8.6 | 10.1 | 11.7 | 1.8 |
| 100 | 5.55 | 7.32 | 9.1 | 10.9 | 12.8 | 14.7 | 1.1 |
Product Images
